LED light
LEDs provides a better light to the cooking area helping in food preparation, offering 90% less energy and lasting longer than conventional bulbs.
ProductHoodsHoods3690169819CDG9MBGGLED lightDÉCORfilterAttr:DécorfilterAttr:BlackfilterAttr:Wall-mountedenergyClass:B
Diameter of air outlet (mm)150
Noise level (dB(A) re 1 pW)66
Min./Max. extraction rate (m3/hr)430
Height of the product (mm) 1040Depth of the product (mm) 330Width of the product (mm) 900
Packaged Product Height (mm) 490Packaged Product Depth(mm) 410Width of the packed product (mm) 990
Technical Specifications
MAIN FEATURES
- Model
- CDG9MBGG
- Product code
- 36901698
- EAN Code
- 8059019037233
- Installation type
- Wall-mounted
- Typology
- Décor
TECHNICAL FEATURES
- Connectivity
- None
- Frequency (Hz)
- 50
- Grease filter type
- Multilayer
- Total power of the lamps (W)
- 2
- Type of control
- Mechanical
- Number of motors
- 1
- Type of lamps used
- LED
- Voltage (V)
- 220-240
PROGRAMMES AND FUNCTIONS
- Number of speed settings
- 3
AESTHETIC
- Colour
- Black
- Material body
- BLACK+BLACK GLASS
PERFORMANCE
- Air flow at at intensive or boost setting (m3/h)
- 0
- Min./Max. extraction rate (m3/hr)
- 430
- Energy Efficiency class (2010/30/EC)
- B
- Noise level (dB(A) re 1 pW)
- 66
- Power (W)
- <1000 W
DIMENSIONS
- Height of product without chimney (mm)
- 410
- Diameter of air outlet (mm)
- 150
- Height of the product (mm)
- 1040
- Width of the product (mm)
- 900
- Depth of the product (mm)
- 330
- Packaged Product Height (mm)
- 490
- Width of the packed product (mm)
- 990
- Packaged Product Depth(mm)
- 410
- Gross weight (kg)
- 17.4
- Net weight (kg)
- 14.5
