3 speeds
Three different speeds to set the air flow at the correct level according to your needs.
Diameter of air outlet (mm)150
Noise level (dB(A) re 1 pW)67
Min./Max. extraction rate (m3/hr)620
Height of the product (mm) 1000Depth of the product (mm) 480Width of the product (mm) 600
Packaged Product Height (mm) 540Packaged Product Depth(mm) 315Width of the packed product (mm) 600
Technical Specifications
MAIN FEATURES
- Model
- CCH6MX
- Product code
- 36901848
- EAN Code
- 8059019059587
- Installation type
- Wall-mounted
- Typology
- Freestanding Wall Decorative
TECHNICAL FEATURES
- Connectivity
- None
- Frequency (Hz)
- 50/60
- IoT App
- None
- Grease filter type
- Multilayer cassette
- Total power of the lamps (W)
- 2
- Type of control
- Mechanical
- Number of motors
- 1
- Type of lamps used
- LED
- Voltage (V)
- 220-240
PROGRAMMES AND FUNCTIONS
- Number of speed settings
- 3
AESTHETIC
- Colour
- Stainless Steel
- Material body
- stainless steel
PERFORMANCE
- Air flow at at intensive or boost setting (m3/h)
- 0
- Min./Max. extraction rate (m3/hr)
- 620
- Energy Efficiency class (2010/30/EC)
- C
- Noise level (dB(A) re 1 pW)
- 67
- Power (W)
- <1000 W
DIMENSIONS
- Height of the chimney (mm)
- 0
- Height of product without chimney (mm)
- 345
- Diameter of air outlet (mm)
- 150
- Height of the product (mm)
- 1000
- Width of the product (mm)
- 600
- Depth of the product (mm)
- 480
- Packaged Product Height (mm)
- 540
- Width of the packed product (mm)
- 600
- Packaged Product Depth(mm)
- 315
- Gross weight (kg)
- 10
- Net weight (kg)
- 8.3
