3 speeds
Three different speeds to set the air flow at the correct level according to your needs.
Diameter of air outlet (mm)120
Noise level (dB(A) re 1 pW)70
Min./Max. extraction rate (m3/hr)335.2
Height of the product (mm) 100Depth of the product (mm) 496Width of the product (mm) 896
Packaged Product Height (mm) 560Packaged Product Depth(mm) 160Width of the packed product (mm) 955
Technical Specifications
MAIN FEATURES
- Model
- CSD9MX
- Product code
- 36901846
- EAN Code
- 8059019059563
- Installation type
- Built-in
- Typology
- Standard
TECHNICAL FEATURES
- Connectivity
- None
- Frequency (Hz)
- 50/60
- IoT App
- None
- Grease filter type
- Multilayer
- Total power of the lamps (W)
- 2
- Type of control
- Mechanical
- Number of motors
- 2
- Type of lamps used
- LED
- Voltage (V)
- 220-240
PROGRAMMES AND FUNCTIONS
- Number of speed settings
- 3
AESTHETIC
- Colour
- Stainless Steel
- Material body
- STAINLESS STEEL
PERFORMANCE
- Air flow at at intensive or boost setting (m3/h)
- 0
- Min./Max. extraction rate (m3/hr)
- 335.2
- Energy Efficiency class (2010/30/EC)
- E
- Noise level (dB(A) re 1 pW)
- 70
- Power (W)
- <1000 W
DIMENSIONS
- Height of the chimney (mm)
- 0
- Height of product without chimney (mm)
- 100
- Diameter of air outlet (mm)
- 120
- Height of the product (mm)
- 100
- Width of the product (mm)
- 896
- Depth of the product (mm)
- 496
- Packaged Product Height (mm)
- 560
- Width of the packed product (mm)
- 955
- Packaged Product Depth(mm)
- 160
- Gross weight (kg)
- 8.8
- Net weight (kg)
- 7.5
