LED light
LEDs provides a better light to the cooking area helping in food preparation, offering 90% less energy and lasting longer than conventional bulbs.
Height of the product (mm) 1030Depth of the product (mm) 505Width of the product (mm) 900
Packaged Product Height (mm) 570Packaged Product Depth(mm) 390Width of the packed product (mm) 955
3 speeds
Three different speeds to set the air flow at the correct level according to your needs.
Technical Specifications
MAIN FEATURES
- Model
- CTS9CX
- Product code
- 36901647
- EAN Code
- 8059019024486
- Installation type
- Wall-mounted
- Typology
- Freestanding Wall Decorative
TECHNICAL FEATURES
- Connectivity
- None
- Frequency (Hz)
- 50
- IoT App
- None
- Grease filter type
- Multilayer
- Total power of the lamps (W)
- 3
- Type of control
- Digital
- Number of motors
- 1
- Type of lamps used
- LED
- Voltage (V)
- 220-240
PROGRAMMES AND FUNCTIONS
- Boost position
- Yes
- Number of speed settings
- 3
AESTHETIC
- Colour
- Stainless Steel
- Material body
- INOX
PERFORMANCE
- Air flow at at intensive or boost setting (m3/h)
- 978.2
- Min./Max. extraction rate (m3/hr)
- 641.5
- Energy Efficiency class (2010/30/EC)
- A
- Power (W)
- <1000 W
DIMENSIONS
- Height of the chimney (mm)
- 980
- Height of product without chimney (mm)
- 50
- Diameter of air outlet (mm)
- 150
- Height of the product (mm)
- 1030
- Width of the product (mm)
- 900
- Depth of the product (mm)
- 505
- Packaged Product Height (mm)
- 570
- Width of the packed product (mm)
- 955
- Packaged Product Depth(mm)
- 390
- Gross weight (kg)
- 17
- Net weight (kg)
- 14.5
