Aluminium filter
Aluminium filter guarantee better durability and performance.
Diameter of air outlet (mm)-
Noise level (dB(A) re 1 pW)67
Min./Max. extraction rate (m3/hr)440
Height of the product (mm) 200Depth of the product (mm) 298Width of the product (mm) 898
Packaged Product Height (mm) 360Packaged Product Depth(mm) 225Width of the packed product (mm) 945
Technical Specifications
MAIN FEATURES
- Model
- CBT9240/4XX
- Product code
- 36901612
- EAN Code
- 8059019014876
- Installation type
- Wall-mounted
- Typology
- Built-in/Telescopic
TECHNICAL FEATURES
- Connectivity
- None
- Frequency (Hz)
- 50/60
- IoT App
- None
- Grease filter type
- Multilayer
- Total power of the lamps (W)
- 2.5
- Type of control
- Rocker
- Number of motors
- 2
- Type of lamps used
- Halogen
- Voltage (V)
- 220-240
PROGRAMMES AND FUNCTIONS
- Number of speed settings
- 2
AESTHETIC
- Colour
- White
- Material body
- white + squared stainless steel frontal with details inox
PERFORMANCE
- Air flow at at intensive or boost setting (m3/h)
- 0
- Min./Max. extraction rate (m3/hr)
- 440
- Noise level (dB(A) re 1 pW)
- 67
- Power (W)
- UNDEFINED
DIMENSIONS
- Height of product without chimney (mm)
- 200
- Height of the product (mm)
- 200
- Width of the product (mm)
- 898
- Depth of the product (mm)
- 298
- Packaged Product Height (mm)
- 360
- Width of the packed product (mm)
- 945
- Packaged Product Depth(mm)
- 225
- Gross weight (kg)
- 10.5
- Net weight (kg)
- 9
