CBT9240/3X



Hoods BUILT-IN

Built-in, Built-in/Telescopic, Silver, LED, steel, Silver
Diameter of air outlet (mm)120
Noise level [dBA]64
Air flow at Max speed Qmax (m3/h)329
Height of the product 175Depth (mm) 280Product Width (mm) 900


Height of the packed product (mm) 355Depth of the packed product (mm) 240Width of the packed product (mm) 950



Aluminium filter

Aluminium filter guarantee better durability and performance.

LED light

LEDs provides a better light to the cooking area helping in food preparation, offering 90% less energy and lasting longer than conventional bulbs.

Detail Sheet

Product name / Commercial code
CBT9240/3X
Product code
36901044
EAN Code
8016361979208
Installation type
Built-in
Typology
Built-in/Telescopic
Connectivity
None
Frequency (Hz)
50
Total power of the lamps (W)
2
Type of control
Mechanical
Number of motors
1
Type of lamps used
LED
Voltage (V)
220-240
Number of speed settings
3
Colour
Silver
Material body
steel
Air flow at Max speed Qmax (m3/h)
329
Energy efficiency class - NEW (2010/30/EC)
B
Noise level [dBA]
64
Power (W)
<1000 W
Height of product without chimney (mm)
175
Diameter of air outlet (mm)
120
Height of the product
175
Product Width (mm)
900
Depth (mm)
280
Height of the packed product (mm)
355
Width of the packed product (mm)
950
Depth of the packed product (mm)
240
Gross weight (kg)
10.6
Net weight (kg)
9.2
